Automatic Capsule Printing Machine

Automatic Capsule Printing Machine

Automatic Capsule Printing Machine is utilized for fast printing, high quality, and high adaptability, which is widely applied to axial printing on capsules and tablets that are of different variety and specifications.

Our AI-CP Capsule printing machine is suitable for printing on the different sizes of capsules (Hard & soft gelatin capsules) and tablets (tablets with unusual shape) and is extensively used in the pharmaceutical industry. These high-end Capsule Printing Machines are operated conveniently by applying the advanced variable frequency control systems which are perfectly coupled with other machines making it perfect for product printing on capsules.

Salient features of Capsule Printing Machine:
  • Fully Automatic printing machine for any capsule/tablet sizes.
  • Tablet printing machine is designed for one or double-sided printing in one or different colors.
  • 100% feeding output. (Feeding output depends on the quality & shapes of tablet/capsules)
  • Prints on any shape-Round, Oval, Hexagonal, and Triangular etc- Wax, Sugar or film coated tablets.
  • Provides sharp printing on both capsule & tablets.
  • Minimum air requirement 2 Kg to 6 Kg.
  • Imported pneumatic components used for better performance.
  • Hardened gears and shafts give longer life workability.
  • A versatile, trouble free, easy to operate machine.

Technical Specification of Automatic Capsule Printing Machine:
Sr. No. Parameters Specification
1 Out put It is capable to print 70,000 - 80,000 capsules/ hour
2 Electric supply 440 Volts (220 Volts AC), 50 Hz
3 Electric motor 0.5 H.P. Main Motor, 1 HP blower
4 Dimension 1880 mm x450 mm x 1300 mm
5 Machine weight 400 kg (approx.)
6 Pneumatic line Filtered and moisture free air at 4 kg/cm2 pressure. External source
7 Vacuum line 150 m3/ h (inbuilt in machine)
