Automatic Linear Bottle Capping Machine
Automatic Linear Bottle Capping Machine Model: AI-LBCM 150 is suitable for Round or irregular shapes of Glass, Plastic, PET, LDPE, HDPE Bottles with maximum speed of 150 Bottles per minute depending on Bottle Diameter, Bottle Height, Bottle Shape and Measuring Cup / Cap Size.
Machine with special Linear Design with No Change Parts system for Change in Bottle Size. Machine with Totally Synchronized Front and Back Bottle Holding Belt with Top Stabilizing and Pressing Belt System.
Specially Machine construction in Stainless Steel finish including machine M.S. frame structure with Stainless Steel Cladding/Enclosures. Machine is ideal for application in Pharmaceutical, Food, Pesticides, Cosmetic & Other Industries. Machine with user friendly operation to handle various type and size of bottles.
The Machine is equipped with Orientation type Cap Feeder or Vibratory type Bowl Feeder depending on cap shape and size for continues feeding of Measuring Cup / Cap for online operation on any liquid of powder filling line. Machine suitable for various sizes of Bottles and Measuring Cup / Cap with the help of change parts. Machine is suitable for application in Pharmaceutical and other industries requiring higher production speed on automatic online operation.
Salient Features of Bottle Capping Machine:
Additional Features of Linear Bottle Capping Machine:
Technical Specification of Linear Bottle Cap Sealing Machine:
| Model | AI-LBCM 150 |
| Bottle Size | Diameter Up to 85mm* or other Shape bottle with proper base |
| Bottle Height | 300mm* Maximum |
| Cap Size | Actual Samples required |
| Electrical | 415VAC 3Phase and 220 VAC Single Phase Power Supply (50 Hz) with A.C. Drive |
| Power | 2.0 H.P. |
| Conveyor Height | 850-900 mm adjustable |
| Overall Dimensions | 1750 mm (L) x 780 mm (W) x 1875 mm (H) |
| Net Weight | 550 Kilograms |
