Automatic Liquid Bottle Filling Machine

Automatic Liquid Bottle Filling Machine

Automatic Liquid Bottle Filling Machine: AI-BFM 4 is compact, versatile and enclosed in elegantly matt finish body. This machine provides maximum output up to 80 bottles per min. This machine model is used in Pharmaceutical, Food, Dairy, Chemical, Cosmetic and Beverages industry.
The speed of Bottle Filling Machines depends on nature of Liquids, container Diameter, container Height, container Neck Size and Filling Volume. Machine construction in fully Stainless-Steel finish including machine frame structure as per cGMP guidelines. Machine with Optional Turn Tables at In-feed and Out-feed with individual drives to match the speed of incoming and outgoing Bottles for smoother operation. All contact parts of machine model are Stainless Steel 316 only.

Special Features of Bottle Filling Machine:
  • No Bottle - No Fill System, No Bottle - Machine Stop System
  • All contact parts made of Ss316 material with easy removal system for Auto-Claving/Sterilization/Cleaning
  • Machine construction in SS 304 material
  • Diving Nozzle for Foam free filling
  • Very High Fill Accuracy
  • Automatic Infeed and Exit of Bottles
  • Minimum Change Over time
  • Unique Free Spinning Bottle Separator- No pneumatic operation
  • Built-in A.C. Variable Freq. Drive System

Additional Items of Bottle Filler Machine:
  • Automatic conveyor washing system.
  • Nitrogen flushing before and after filling.
  • PLC Control
  • Acrylic cabinet.
  • On line pre-inspection system.
  • Float tank (Holding tank) with or without stirrer.

Technical Specification of Automatic Bottle Filling Machine:
Model No. AI-BFM 4
Bottle Diameter Up to 90 mm*
Filling Range 25 ml to 500 ml with help of suitable change parts / Syringe
Accuracy +/- 1% Depending on Liquid with Single Dose
Electrical 220 VAC Single Phase Power Supply (50 Hz)
Power 2.0 H.P.
Production Output Max. 80 Bottles per minute
Syringe Filling Range 10ml to 50ml,50ml to 100ml, 100ml to 250ml and 250ml to 500ml
Conveyor Height 800 to 850 mm
Overall Dimensions 1830 mm (L) x 800 mm (W) x 1550 mm(H)
Net Weight 350 Kgs.
* Specification offered is for reference purpose only.
