Automatic Rotary Vial Washing Machine

Automatic Rotary Vial Washing Machine

Automatic Rotary Vial Washing Machine Model AI-VRW is designed to wash glass vials without contact of non-contact machine parts with glass Vials. Automatic Rotary Vial Washing Machine model is having gripper system to holds the vial from Neck and invert the vials till the washing operation takes place than again after washing process release the vial on outfeed star wheel arrangement in vertical position this ensures positive wash of vials. Our machine model is suitable to wash 2ml to 100ml Glass Vials/ Containers with the help of change parts. Glass Vial feeds through Turn Table to infeed Star Wheel and specially designed Gripper hold the Vial from neck and invert the vial and move it further on rotary moving system for Washing process.

AI-VRW model suitable for application in Pharmaceutical & Biotech Industries, The Vials traveling in neck down position above washing Needles and moves along with the Needle bar ensures maximum time for washing once the needle enters in the vial neck. Machine with Standard Six Different Washing Stations each of 6 Needle for optimum Washing and the sequence can be change as per customers specific requirement. This machine model is 0 also having external wash mechanism for optimum washing of Vials.

Salient Features of Rotary Vial Washing Machine:
  • 18 Jets for 6 Internal washing zones
  • 6 Jets for External Washing of Vials
  • All contact parts made of SS 316 material
  • Machine construction in SS 304 Material
  • 10 Cassette of Grippers each having 3 Grippers
  • Suitable for 2ml to 50ml and in special design up to 100ml size
  • Washing sequence can be made as per customers’ requirements.
  • Optionally available 2 Pumps and 2 Tanks
  • Each washing zone with independent circuit to avoid contamination
  • Automatic Infeed and Exit of Vials

Technical Specification of Rotary Washing Machine:
Model AI-VRWM 120 AI-VRWM 240
Suitable For 2ml to 100ml Vials with the help of change parts
Production Output Max. 120 per minute Max. 240 per minute
Input Specification
Vial Diameter 14mm to 56mm 14mm to 56mm
Vial Height 32mm to 110mm 32mm to 110mm
Power Specification 4 H.P., 3 Phase 50 Hertz, 4 wire system 4 H.P., 3 Phase 50 Hertz, 4 wire system
Optional Accessories Programmable Logic Control (System) with MMI Aluminium Profile Cabinet covering full machine Programmable Logic Control (System) with MMI Aluminium Profile Cabinet covering full machine
Utility Requirement:
Air Consumption 20 CFM 20 CFM
Water Consumption 250 to 500 Litre per hour depending on Vial Size 250 to 500 Litre per hour depending on Vial Size
Water Tank & Pump 2 nos. each with 25 Litres Capacity & Centrifugal pumps
Conveyor Height 875-950 mm adjustable
Overall Dimension: 2050mm (L) X 2000mm (W) X 1210mm (H) 2450mm (L) X 2000mm (W) X 1300mm (H)
