Automatic Sticker Labeling Machine

Automatic Sticker Labeling Machine

Automatic Sticker Labeling Machine Model: AI-SLM 1H is suitable for labeling on round Vials and smaller size of Bottles. The machine incorporates modern sophisticated Micro Processor Control Label Dispensing system with user friendly Sensing system for Label and Product. It is capable of Labeling up to 100 units per minute depending on product diameter and label size. Machine suitable for Vials and Small Sizes of Bottles from Glass, Plastic, PET, HDPE, PP etc. with speed range of 60 to 100 products per minute.

The Sticker Labeling Machine has its own unique single point synchronized speed control system. The Inbuilt Automated Label Length detection systems eliminates any need for manually feeding and storing of Label Length data in memory and retrieving the same every time for change of Label Size & re-starting the machine. The System thus saves valuable time, avoiding machine-down time, and helps achieve higher production.

Special Features of Sticker Labeling Machine:
  • No Label Data Input/retrievals require for any Label Size
  • No Change Parts for Product and Label size
  • Single Pot On-line Speed Variation control
  • Synchronized speed of Label Dispensing, Conveyor and Pressing Device
  • Virtually Maintenance free machine
  • Easy to change label application height
  • User Friendly Label Placing Adjustments
  • Self Protected against Voltage Fluctuations
  • Suitable for On-Line Inkjet and Contact Coding System
  • Suitable for Partial, Full Wrap Around and Overlap Labelling
  • Built In A.C. Variable Frequency Drive System.
  • Fully Stainless Steel finish Machine

Additional Features of Sticker Labeler Machine:
  • Label Roll Empty - Machine Stop System with Alarm
  • Missing Label in Roll - Machine Stop System with Alarm
  • Special Label Sensor for sensing Transparent Film Labels which does not have
  • any sensing mark on it.
  • Option of Contact Coder, Hot Foil Coder, HP Cartridge Coder and Inkjet Coder with various speed range available.
  • Low Compressed Air - Machine Stop with Alarm system for pneumatically o- operated coding system
  • Turn Table and Packing Conveyor

Technical Specification of Automatic Sticker Labeling Machine:
Model No. AI-SLM 1H
Label Height 8 mm to 70 mm Standard*
Label Length 12 mm to 120mm Appx.*
Label Roll Dia. 300 mm
Core Diameter : 75/76 mm
Gap Between two Labels Approx 3 mm
Product Diameter 15 mm to 70 mm*
Electrical 220 VAC Single Phase Power Supply (50/60 Hz)
Power 1.5 Amp.
Capacity 0.75 Kw
Speed Up to 120 Labels per minute depending on Product and Label Size
Conveyor height 830-875 mm* adjustable
Overall dimension 1770 mm(L) X 770 mm(W) X 1000 mm (H)
Machine Direction of Movement Left to Right from operator side
* Specification offered is for reference purpose only.
Note: This model is available with limited optional features only, contact us for more detail
