Semi Automatic Capsule Counting Machine

Semi-Automatic Single Disc Capsule Counting Machine is compact highly efficient and cost-effective machine model/ It can easily count and pack capsules & tablets of any size. The design of the Machine is ergonomic, easy to handle and maintain for operators. The trouble-free operations and accurate results of these semi-automatic machines help in maintaining GMP standards.

Salient Features of Semi-Automatic Capsule Counter Machine:

• Each disc is custom designed and manufactured to meet customer’s needs.
• The machine is provided with adjustable filler which can be elevated from 20 to 25 degrees, to facilitate entry of the products into the disc holes.
• The machine is fitted with superior quality delivery chutes which direct the product from the counting disc into the stainless-steel filler tubes of various sizes, to suit different containers, suitable to work on 3 phase ac, 1 HP motor, 1440 rpm with variable speed drive.
• The entire machine is mounted on MS body.
• Simple operation, only one operator required, and operating training can be done in 10 min.
• The machine is provided with one countable type disc.
• G.M.P. model: M.S. body of the machine cladded with SS sheet”.

Technical Specification of Semi-Automatic Capsule Counting Machine

Contact Parts : Stainless Steel 316
Power consumptions : 0.75 KW / 1 H.P.
Air Consumption : 40 Litre @ 6 bar.
Power supply :A.C. 3 Phase440 V, 50 Hz Motor-1440rpm
Packing Case Dimension : 1981 (L) X 1219 (W) 1016 (H) mm
Net Weight : 290 Kg.
Gross Weight : 425 Kg.
