Small Automatic Capsule Filling Machine


ACF LAB Small Automatic Capsule Filling Machine is perfect choice for small lab scale and R&D operations. Machine suitable for filling powder as well as pellets into different size of capsules. Small Automatic Capsule Filler suitable to fill size #00, 0, 1, 2, 3 & 4 capsules with help of format parts. Machine working stations like Capsule Feeding, Seapration, Powder Dosing, Capsule Joining and Capsule Ejection all operations synchronize with one motor only.

Machine equipped with touch screen HMI for easy of operation. Lab Capsule Filler is so compact is size that it can be putted onto table or platform in any Laboratory. This R&D model machine can fill up to 2500 capsules per hour with speed varible option onto control panel. Filling Machine Lab Model is suitabnle for HPMC and Veg capsules both and can have tablet feeding attachment upon specific customer request.

The machine control is by means of a programmable logic controller with touch screen HMI with a very user friendly operable front end. Machine equipped with Venturi for vacuum generation hence no need for vacuum pump.

Special Features of Small Automatic Capsule Filling Machine

  • Compact GMP model
  • Machine is equipped with complete safety and protection devices, operation is steady and credible.
  • Compact, sturdy, covered with stainless steel panels, hood covered with acrylic guard.
  • Efficient capsule separation by means of vacuum.
  • Touch Screen HMI, featuring user friendly controls.
  • Quick Fill weight adjustments.
  • Tamping Mechanism for powder filling enables capsules to be filled with minimum weight variation.
  • Variable AC frequency drive for speed adjustment.
  • Simple to operate and easy to maintain.
  • Working of the machine is as follows capsule loading and separation, reject capsule disposal, powder (Bulk) filling, capsule closing (locking) and its ejection completely automatically.

Technical Specification of Small Capsule Filler:

Model No. ACF LAB
Production Output Up to 2500 Capsules/hour
Capsule Size Combinations 00, 0, 1, 2, 3 & 4
Product Contact Parts AISI SS 316
Power Requirement 0.5 H.P.
Power Voltage 220 Volts, Single Phase, 50 Hertz
Compressed Air 12 to 15 CFM @ 6 Bar
Ambient Temperature/td> 21°C ±3°C
Overall Dimension 625mm (L) x 625mm (W) x 900mm (H)
Net Weight 150 kgs. (approx.)
Gross Weight 250 kgs. (approx.)
