Vacuum Tray Dryer Model: AI-VTD is suitable for rapid drying of thermal sensitive materials easily resolved, polymerized of deteriorated under higher temperature. Sterilization can be conducted prior to the drying process, during which no matter is allowed to enter the product. Static vacuum dryer eliminates the configuration damage of the drying materials therefore widely used in pharmaceutical, chemicals and foodstuff etc.
Principally, drying under vacuum is environmentally friendly because the Evaporated Solvents can easily be re-condensed. These solvents can then either be recycled or disposed of without any problem.
Drying of solvents in Ex-proof ovens may solve the safety problem in the oven but not the environmental aspect. The solvent vapour is blown out of the oven through the exhaust system Furthermore, there is a risk of uncontrolled mixture formation.
Special Features of Tray Dryer:
- Mani body and door are made in SS 316 with rigid flange
- Shelves (hollow type) in SS 316 with baffles
- Trays (without back folding) in SS 316
- Condenser (shell & tube) and Receiver in SS 304 for solvent recovery
- Digital Temperature Indicator (FLP) at H.W. Inlet and Outlet
- Digital Temperature Indicator (FLP) at vacuume line
- Dial type vacuume gauge in vacuum line
- Dial type Temperature gauge in body
- Glass view provided on door and receiver
- Flow glass provided to monitor condensation between condenser and receiver
- Validation port
- Provision for Nitrogen purging
- Vacuum break valve provided in vacuum line
- Construction and finish as per cGMP standards
Additional of Tray Dryer:
- Condenser and receiver are made in SS 316
- 300 mm wide SS 304 skirting all along the flange
- 50 mm thick glass wool insulation on the vacuum chamber outer surface except door. The insulation is enclosed and covered with removable SS 304 angle frame
- Digital temperature controller with pneumatic operated valve at hot water/steam inlet
- 2 stage water ring type vacuum pumps (partial SS) run by FLP motor
- Hot water system with circulation pump
Testing Parameters of Tray Dryer:
The vacuum dryer shelves are hydro-tested 5 kg/cm2 assembled condition. The vacuum chamber is tested for leaks under vacuum
Capacity of Tray Dryer:
Standard models range from 3 trays to 96 trays
